Kioti LB1714
|
|
| Production | |
| Manufacturer | Kioti (a part of Daedong) |
| Compact Utility tractor | |
| Built in Daegu, South Korea | |
| Kioti LB1714 Engine | |
| Daedong 0.9L 3-cyl diesel | |
 Engine details ... |
| Kioti LB1714 Transmission | |
| 8-speed partial synchromesh with mechanical shuttle | |
 Transmission details ... |
| Kioti LB1714 Power | |
| Engine | 17 hp 12.7 kW |
| Mechanical | |
| Four-wheel drive | |
| Steering | manual |
| Wet disc brakes | |
| Two-post ROPS. | |
| Photos | |
 | |
 Kioti LB1714 photos... | |
| Hydraulics | |
| Total flow | 4.5 gpm 17.0 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 1,000 lbs 453 kg |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| Clutch | overrunning |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@2405 |
| 1000@2400 | |
| Front PTO | engine |
| Front PTO Type | 2600 |
| Dimensions & Tires | |
| Wheelbase | 56 inches 142 cm |
| Weight | 1,900 lbs 861 kg |
| Front tire | 6-12 |
| Rear tire | 9.5-20 |
 Full dimensions and tires ... | |
| LB1714 Serial Numbers | |
| Location: | On the tractor's transmission housing ahead of the clutch pedal. |
| 1988 | 400001 |
| 1989 | 500001 |
| 1990 | 600001 |
| 1991 | 700001 |
| 1992 | 800001 |
| 1993 | 900001 |
FAQ: How to read a serial number table. | |
| References | |
 | |
| LB1714 Four Wheel Drive Compact Tractor published in 1987, by Kitoi |
