Ford 4000SU
| | 1970 - 1976 |
| Utility tractor |
|
| Production |
| Manufacturer: | Ford
|
| Type: | Utility tractor
|
| The Ford 4000SU - Special Utility - used the engine from a Ford 4000 fit into a smaller chassis using components from the Ford 3000. |
| Ford 4000SU Power |
| Engine (net): | 57 hp
42.5 kW
|
| PTO (claimed): | 52 hp
38.8 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Final drives: | inboard planetary
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Open operator station or two-post ROPS.
|
| Transmission: | 8-speed
|
 Transmission details ... |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2500 psi
172.4 bar
|
| Pump flow: | 5.4 gpm
20.4 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| | II*Optional
|
| Rear lift (at 24"/610mm): | 1700 lbs
771 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Electrical |
| Ground: | negative
|
| Charging system: | generator
|
| Charging amps: | 22
|
| Battery volts: | 12
|
| Battery AH: | 80 (gas)
|
| | 128 (diesel)
|
