International Harvester B-614
|
|
| Production | |
| Manufacturer | International Harvester |
| Standard-tread tractor | |
| Built in Doncaster, England | |
| Total built | 3,947 |
| International Harvester B-614 Engine | |
| International Harvester 4.6L 4-cyl diesel | |
 Engine details ... |
| International Harvester B-614 Power | |
| Engine | 62.5 hp 46.6 kW |
| Drawbar (claimed) | 52 hp 38.8 kW |
| PTO (claimed) | 55 hp 41.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station. |
| Capacity | |
| Fuel | 20.4 gal 77.2 L |
| Hydraulic system | 4.2 gal 15.9 L |
| Hydraulics | |
| Type | open center |
| Capacity | 4.2 gal 15.9 L |
| Pressure | 2000 psi 137.9 bar |
| Pump flow | 7.2 gpm 27.3 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at ends) | 3700 lbs 1678 kg |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| independent OptOptional | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1150 |
| Dimensions & Tires | |
| Weight | 6188 lbs 2806 kg |
| Front tire | 7.50-16 |
| Rear tire | 12-38 |
 Full dimensions and tires ... | |
| B-614 Serial Numbers | |
| 1963 | 501 |
| 1964 | 508 |
| 1965 | 981 |
| 1966 | 2191 |
| 1967 | 3017 |
| 1968 | 3964 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Charging system | generator |
| Batteries | 2 |
| Battery volts | 6 |
| References | |
 | |
| International 1917-1961 Vintage Tractor Special by Allen Condie* | |
| The Roar of Dust and Diesel - A Story of International Harvester Doncaster by Mike Teanby | |
| World Wide Farm Equipment Buyer's Guide published in 1968, by International Harvester* | |
| McCormick B-614 Tractor published in 1965, by International Harvester | |
| *Publication contains known errors. |
