Bombardier MPV-20
| | 1984 - 1994 |
| Truck-type tractor | | Hinomoto built |
|
| Production |
| Distributor: | Bombardier
|
| Manufacturer: | Hinomoto
|
| Type: | Truck-type tractor
|
| Factory: | Japan
|
| The Bombardier MPV-20 is the same as the Hinomoto JF1. |
| Bombardier MPV-20 Power |
| Engine (gross): | 20 hp
14.9 kW
|
| PTO (claimed): | 16.6 hp
12.4 kW
|
| Mechanical |
| Chassis: | 4x4 4WD
|
| Steering: | manual
|
| Brakes: | dry shoe
|
| Cab: | Two-post ROPS. Cab optional.
|
| Transmission: | 9-speed
|
 Transmission details ... |
| Capacity |
| Fuel: | 4.8 gal
18.2 L
|
| Hydraulic system: | 5.1 gal
19.3 L
|
| Hydraulics |
| Capacity: | 5.1 gal
19.3 L
|
| Pressure: | 2490 psi
171.7 bar
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 1814 lbs
822 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@2363
789@2363
|
| Electrical |
| Ground: | negative
|
| Charging system: | Hitachi LR135-588 alternator
|
| Charging amps: | 35
|
| Battery CCA: | 433
|
| Battery volts: | 12
|
| Page information |
| Last update: | February 22, 2019
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Bombardier MPV-20 photos...
Full dimensions and tires ...
Attachment details ...
