Tractors > Allis Chalmers > D12 High Clearance

Allis Chalmers D12 High Clearance

Allis Chalmers D12 High Clearance tractor photo
1959 - 1967
High-Clearance tractor






Production:

Manufacturer:Allis Chalmers


Variants:

D12:utility tractor


Allis Chalmers D12 High Clearance Engines:

   Allis-Chalmers 2.3L 4-cyl gasoline
   Allis-Chalmers 2.4L 4-cyl gasoline
full engine details ...


Capacity:

Hydraulic system:0.75 gal [2.8 L]


Rear Hitch:

Type:Snap-Couple


3-Point Hitch:

Rear Type:I


Power Take-off (PTO):

Rear RPM:540


Dimensions & Tires:

Wheelbase:78.75 inches [200 cm]
Weight:3,080 lbs [1397 kg]
Rear tire:9x36
full dimensions and tires ...


D12 High Clearance Serial Numbers:


- Serial numbers unknown -



Allis Chalmers D12 High Clearance Power:

Drawbar (claimed):25.75 hp [19.2 kW]
PTO (claimed):30 hp [22.4 kW]


Mechanical:

Chassis:4x2 2WD
Steering:manual
Brakes:differential mechanical shoe
Cab:Open operator station


Hydraulics:

Type:live
Capacity:0.75 gal [2.8 L]
Rear valves:1 or 2


Belt Pulley:

RPM:1220
Speed:2556 ft/min [779.07 meters/min]


Battery:

Number:1
Volts:6
