    Hinomoto C172

    Hinomoto C172 tractor photo
    1980 - 1985
    Compact Utility tractor






    Production:

    Manufacturer:Hinomoto
    Factory:Japan


    Variants:

    C172:2WD
    C174:4WD


    Hinomoto C172 Engine:

       Toyosha 1.0L 3-cyl diesel
    full engine details ...


    Capacity:

    Fuel:3.7 gal [14.0 L]


    3-Point Hitch:

    Rear Type:I


    Power Take-off (PTO):

    Rear RPM:540 (1.375)


    Dimensions & Tires:

    Wheelbase:50.8 inches [129 cm]
    Weight:1280 lbs [580 kg]
    full dimensions and tires ...


    C172 Serial Numbers:


    - Serial numbers unknown -



    Hinomoto C172 Power:

    Engine (gross):20 hp [14.9 kW]
    Engine (net):18 hp [13.4 kW]
    PTO (claimed):15 hp [11.2 kW]


    Mechanical:

    Chassis:4x2 2WD
    Steering:manual
    Brakes:drum
    Cab:Open operator station.


    Hydraulics:

    Type:open center


    Electrical:

    Ground:negative
    Charging system:generator
    Charging amps:12.5


    Battery:

    Number:1
    Volts:12
