    Farmall 706

    Farmall 706 tractor photo
    1963 - 1967
    Row-Crop tractor
    Next model:Farmall 756
    Larger:Farmall 806





    The 706 was available with a new Torque Amplifier design that prevented free-wheeling when going downhill. An over-center hand clutch was an option, usually found on Wheatland (standard tread) models. The 706 was available with either the Fast Hitch or a standard 3-point hitch. The PTO featured both 540 and 1000 RPM shafts, both of which turned while in use.


    Production:

    Manufacturer:International Harvester
    Total built:46,146
    Original price (USD):$6,100 (1967)


    Variants:

    Farmall 706:row-crop
    IH 706:standard-tread
    IH 2706:industrial
    706 Hi-Clear:high-crop


    Farmall 706 Engines:

       International Harvester 4.6L 6-cyl diesel
       International Harvester 5.1L 6-cyl diesel
       International Harvester 4.3L 6-cyl gasoline
       Interntional Harvester 4.8L 6-cyl gasoline
    full engine details ...


    Capacity:

    Fuel:33 gal [124.9 L] (gas/diesel)
     39 gal [147.6 L] (LP gas)
    Hydraulic system:17 gal [64.3 L]


    Rear Hitch:

    Type:IH Fast Hitch


    3-Point Hitch:

    Rear Type:2


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540/1000
     1000
    Engine RPMs:540@2100
    1000@2100


    Dimensions & Tires:

    Wheelbase:97.5 inches [247 cm] (2WD)
     94.75 inches [240 cm] (4WD)
    Weight:7530 to 10710 pounds
    Front tire:6.50-16
    Rear tire:15.5-38
    full dimensions and tires ...


    706 Serial Numbers:

    Location:Tractor's clutch housing on left side
    photo of 706 serial number

    1963: 501
    1964: 7073
    1965: 21162
    1966: 30288
    1967: 38521
    Final: 46647

    how to read serial numbers...



    Farmall 706 Power:

    Engine (gross):89 hp [66.4 kW]
    Drawbar (claimed):65 hp [48.5 kW]
    PTO (claimed):73.5 hp [54.8 kW]
    Drawbar (tested):67.46 hp [50.3 kW]
    PTO (tested):76.56 hp [57.1 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Steering:hydrostatic power
    Brakes:hydraulic dry double disc
    Cab:Cab optional, A/C available starting in 1966


    Hydraulics:

    Type:open center
    Capacity:17 gal [64.3 L]
    Valves:1 or 2
    Pump flow:12 gpm [45.4 lpm]
     17 gpm [64.3 lpm] (optional)
     3 gpm [11.4 lpm] (PTO pump)
    Steering flow:9 gpm [34.1 lpm]


    Belt Pulley:

    Diameter:11 inches [27 cm]
    Width:7.5 inches [19 cm]
    RPMs:1055
    Speed:3,038 ft/min [925.98 meters/min]


    Electrical:

    Ground:negative
    Charging amps:25 (generator)
     32 (alternator)


    Battery:

    Number:1 (gas)
     2 (diesel)
    Volts:12 (gas)
     6 (diesel)
    Amp-hours:60 (gas/LP)
     130 (diesel)
