Tractors > International Harvester > D-514

International Harvester D-514

International Harvester D-514 tractor photo
1963 - 1965
Utility tractor






Production:

Manufacturer:International Harvester
Factory:Neuss, Germany
Total built:1199


International Harvester D-514 Engine:

   International Harvester 3.1L 4-cyl diesel
full engine details ...


Capacity:

Fuel:15.3 gal [57.9 L]


3-Point Hitch:

Rear Type:II/I


Power Take-off (PTO):

Rear RPM:540 (1.375)


Dimensions & Tires:

Wheelbase:73.1 inches [185 cm]
Weight:5556 lbs [2520 kg]
Front tire:7.50-16
Rear tire:13-30
full dimensions and tires ...


D-514 Serial Numbers:


- Serial numbers unknown -



International Harvester D-514 Power:

Engine:53 hp [39.5 kW]


Mechanical:

Chassis:4x2 2WD
Steering:power
Cab:Open operator station.


Belt Pulley:

Diameter:11 inches [27 cm]
Width:7.5 inches [19 cm]
RPM:1168
Speed:3366 ft/min [1025.96 meters/min]
