Renault Super 3D
|
|
| Production | |
| Manufacturer | Renault |
| Built in Le Mans, France | |
| Renault Super 3D Engine | |
| MWM 1.8L 2-cyl diesel | |
| Fuel tank | 10.6 gal 40.1 L |
 Engine details ... | |
| Renault Super 3D Transmission | |
| 10-speed gear | |
 Transmission details ... |
| Renault Super 3D Power | |
| Engine | 24 hp 17.9 kW |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Drum brakes | |
| Open operator station. |
| Photos | |
| No photos of the Renault Super 3D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Total flow | 4.8 gpm 18.2 lpm |
| Tractor hitch | |
| Rear lift | 2977 lbs 1350 kg |
| Power Take-off (PTO) | |
| Rear PTO | live |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Wheelbase | 68.1 inches 172 cm |
| Weight | 3903 lbs 1770 kg |
| Front tire | 5.50-16 |
| Rear tire | 11-28 |
 Full dimensions and tires ... | |
| References | |
 | |
| Standard 24PS published in 1966, by Renault |
