Renault Super 3D


Renault Super 3D tractor photo
1965 - 1968
Super D Series
Series map:
Super 2D
Super 3D
Super 4D
19.4kw
17.9kw
22.4kw
Production
ManufacturerRenault
Built in Le Mans, France
Renault Super 3D Engine
MWM 1.8L 2-cyl diesel
Fuel tank10.6 gal
40.1 L
Engine details ...
Renault Super 3D Power
Engine24 hp
17.9 kW
Mechanical
Two-wheel drive
Manual steering
Drum brakes
Open operator station.
Photos
No photos of the Renault Super 3D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Total flow4.8 gpm
18.2 lpm
Tractor hitch
Rear lift2977 lbs
1350 kg
Power Take-off (PTO)
Rear PTOlive
Rear PTO Type540
Dimensions & Tires
Wheelbase68.1 inches
172 cm
Weight3903 lbs
1770 kg
Front tire5.50-16
Rear tire11-28
Full dimensions and tires ...
References
Super 3D references literature
Standard 24PS published in 1966, by Renault
