Landini 5830
Note: the Landini model 5830 is the same as the Massey Ferguson 254. The following data is from the 254 listing. |
Production |
Manufacturer: | Landini
|
Original price: | $20,600 (1987)
|
Landini 5830 Power |
Engine: | 50 hp 37.3 kW
|
PTO (claimed): | 42 hp 31.3 kW
|
Drawbar (tested): | 33.97 hp 25.3 kW
|
PTO (tested): | 43.36 hp 32.3 kW
|
power test details ... |
Mechanical |
Chassis: | 4x4 MFWD 4WD
|
Differential lock: | pedal-operated
|
Steering: | hydrostatic power
|
Brakes: | differential mechanical dry disc
|
Cab: | Two-post ROPS.
|
Transmission: | 12-speed synchromesh
|
Transmission details ... |
Photos |
No photos of the Landini 5830 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics |
Type: | open
|
Pressure: | 2250 psi 155.1 bar
|
Valves: | 2
|
Pump flow: | 9.2 gpm 34.8 lpm
|
Tractor hitch |
Rear Type: | I
|
Control: | draft and position control
|
Rear lift (at ends): | 5,070 lbs 2299 kg
|
Rear lift (at 24"/610mm): | 3,670 lbs 1664 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Rear RPM: | 540/ground
|
Front PTO: | direct-drive
|
Front RPM: | 2250
|
Electrical |
Ground: | negative
|
Battery volts: | 12
|
