Tractors > John Deere > 3045B

John Deere 3045B



John Deere 3045B tractor photo
2018 -
3B Series
Compact Utility tractor
Series map:
3045B
3050B
33.6kw
37.3kw
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Ningbo, China
John Deere 3045B Engine
XinChai 3.0L 4-cyl diesel
Fuel tank17.4 gal
65.9 L
Engine details ...
John Deere 3045B Transmission
12-speed mechanical shuttle
Transmission details ...
John Deere 3045B Power
Engine45 hp
33.6 kW
PTO (claimed)38.2 hp
28.5 kW
Mechanical
Four-wheel drive
Differential lockmechanical rear
Power steering
Mechanical disc brakes
Trailer brakespneumatic OptOptional
Two-post folding ROPS. Cab optional.
Photos
No photos of the John Deere 3045B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2321 psi
160.0 bar
Rear valves1 or 2
Pump flow5.4 gpm
20.4 lpm
Total flow7 gpm
26.5 lpm
Steering flow1.6 gpm
6.1 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)2381 lbs
1080 kg
Rear lift (at 24"/610mm)2046 lbs
928 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchdry disc
Rear PTO Type540/720 (38mm 8-spline)
 540/720 (35mm 6-spline)OptOptional
Engine RPM540@1970
 720@2020
Dimensions & Tires
Wheelbase77.2 inches
196 cm
Weight4409 lbs
1999 kg
Front tire7.50-16
Rear tire11.2-28
Full dimensions and tires ...
3045B Serial Numbers
Location:Serial number plate on the left side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging volts14
Battery volts12
Battery AH90
References
3045B references literature
3B Series Tractors published in 2018, by John Deere
