Massey Ferguson 1233
| | 2001 - 2002 |
| 1200 Compact Series | | Compact Utility tractor | | Iseki built |
|
Series map:
1230
1233
1235
27.0hp
28.4hp
32.0hp
| Production |
| Distributor | Massey Ferguson
|
| Manufacturer | Iseki
|
| Compact Utility tractor |
| Original price was $11,500 in 2002 |
| Massey Ferguson 1233 Power |
| Engine (gross) | 28.4 hp
21.2 kW
|
| Engine (net) | 27.6 hp
20.6 kW
|
| PTO (claimed) | 24.5 hp
18.3 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Mechanical wet disc brakes |
| Two-post fixed ROPS. |
| Photos |
| No photos of the Massey Ferguson 1233 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 6 gal
22.7 L
|
| Hydraulic system | 3.7 gal
14.0 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 3.7 gal
14.0 L
|
| Pressure | 2130 psi
146.9 bar
|
| Valves | 2 OptOptional
|
| Pump flow | 6.0 gpm
22.7 lpm
|
| Total flow | 8.5 gpm
32.2 lpm
|
| Steering flow | 2.5 gpm
9.5 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 1984 lbs
899 kg
|
| Power Take-off (PTO) |
| Rear PTO | transmission
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2327
|
| Mid PTO Type | 2000
|
| Engine RPM | 2000@2500
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 40
|
| Battery CCA | 582
|
| Battery volts | 12
|
| References |
 |
| MF Loaders for Compact & Agricultural Tractors published in 2003, by Massey Ferguson |
| MF 1233-2/4WD published by Massey Ferguson |
