    Chamberlain 4690

    Chamberlain 4690 tractor photo
    1985 - 1986   90 Series
    Row-Crop tractor
    Smaller:Chamberlain 4490






    Production:

    Manufacturer:Chamberlain
    Factory:Welshpool, Australia
    Total built:180


    Chamberlain 4690 Engine:

       John Deere 7.6L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:87.2 gal [330.1 L]
    Hydraulic system:7.2 gal [27.3 L]


    3-Point Hitch:

    Rear Type:III/IIIN
    Control:top-link sensing
    Rear lift (at 24"/610mm):7,681 lbs [3484 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Clutch:hydraulic disc
    Rear RPMs:1000


    Dimensions & Tires:

    2WD fixed Wheelbase:113.5 inches [288 cm]
    2WD Wheelbase:114.3 inches [290 cm]
    4WD Wheelbase:115 inches [292 cm]
    Weight:13779 to 14639 pounds
    Front tire:11.00x16
    Rear tire:24.5x32 (2WD)
    full dimensions and tires ...


    4690 Serial Numbers:


    - Serial numbers unknown -



    Chamberlain 4690 Power:

    Engine (net):163.5 hp [121.9 kW]
    PTO (claimed):154 hp [114.8 kW]


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Steering:hydrostatic power
    Brakes:hydraulic wet disc
    Cab:Cab standard with air-conditioning.


    Hydraulics:

    Type:open center
    Capacity:7.2 gal [27.3 L]
    Pressure:2500 psi [172.4 bar]
    Valves:4 (max)
     3 (with 3pt)
    Total flow:15.6 gpm [59.0 lpm]


    Electrical:

    Charging system:alternator
    Charging amps:70


    Battery:

    Number:2
    Volts:6
