Chamberlain Canelander
| | 1959 - 1973 |
| High-Clearance tractor |
|
| Production |
| Manufacturer: | Chamberlain
|
| Type: | High-Clearance tractor
|
| Factory: | Welshpool, Australia
|
| Chamberlain Canelander Power |
| Engine: | 62 hp
46.2 kW
|
| Drawbar (claimed): | 48 hp
35.8 kW
|
| PTO (claimed): | 55 hp
41.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| Brakes: | mechanical expanding
|
| Cab: | Open operator station.
|
| Transmissions: | 9-speed gear
|
| | 9-speed
|
 Transmission details ... |
| Photos |
| No photos of the Chamberlain Canelander are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel: | 19.5 gal
73.8 L
|
| Hydraulic system: | 2.4 gal
9.1 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 2.4 gal
9.1 L
|
| Pressure: | 1750 psi
120.7 bar
|
| Pump flow: | 9.8 gpm
37.1 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift (at ends): | 3500 lbs
1587 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@1600
|
| Page information |
| Last update: | January 3, 2020
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
