Chamberlain Canelander
|
|
| Production | |
| Manufacturer | Chamberlain |
| High-Clearance tractor | |
| Built in Welshpool, Australia | |
| Chamberlain Canelander Engine | |
| Perkins 4.4L 4-cyl diesel | |
 Engine details ... |
| Chamberlain Canelander Transmissions | |
| 9-speed gear | |
| 9-speed | |
 Transmission details ... |
| Chamberlain Canelander Power | |
| Engine | 62 hp 46.2 kW |
| Drawbar (claimed) | 48 hp 35.8 kW |
| PTO (claimed) | 55 hp 41.0 kW |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Mechanical expanding brakes | |
| Open operator station. |
| Photos | |
| No photos of the Chamberlain Canelander are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 19.5 gal 73.8 L |
| Hydraulic system | 2.4 gal 9.1 L |
| Hydraulics | |
| Type | open center |
| Capacity | 2.4 gal 9.1 L |
| Pressure | 1750 psi 120.7 bar |
| Pump flow | 9.8 gpm 37.1 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at ends) | 3500 lbs 1587 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1600 |
| Dimensions & Tires | |
| Wheelbase | 92 inches 233 cm |
| Weight | 7350 lbs 3333 kg |
| Front tire | 7.50x18 |
| Rear tire | 14.9x38 |
 Full dimensions and tires ... | |
| References | |
 | |
| Canelander published by Chamberlain |
