Tractors > Chamberlain > Super 90

Chamberlain Super 90

Chamberlain Super 90 tractor photo
1962 - 1967
Standard-tread tractor






Production:

Manufacturer:Chamberlain
Factory:Welshpool, Australia
Total built:803


Chamberlain Super 90 Engine:

   General Motors 3.5L 3-cyl diesel
full engine details ...


Capacity:

Fuel:21.6 gal [81.8 L]


Power Take-off (PTO):

Rear RPM:540 (1.375)


Dimensions & Tires:

Wheelbase:85 inches [215 cm]
Front tire:8.25x20
Rear tire:23.1x26
full dimensions and tires ...


Super 90 Serial Numbers:

1962: 1201
1963: 1261
1964: 1429
1965: 1629
1966: 1852
1967: 1979
Final: 2003

how to read serial numbers...



Chamberlain Super 90 Power:

Engine:90 hp [67.1 kW]
PTO (claimed):77 hp [57.4 kW]


Mechanical:

Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.


Belt Pulley:

Diameter:13 inches [33 cm]
Width:7 inches [17 cm]
RPM:810


Battery:

Volts:12
