Chamberlain 55DA


Chamberlain 55DA tractor photo
1954 - 1957
Standard-tread tractor
Production
Manufacturer:Chamberlain
Type:Standard-tread tractor
Factory:Welshpool, Australia
Total built:341
Variants
55KA:kerosene engine
55DA:diesel engine
Chamberlain 55DA Power
Drawbar (claimed):52 hp
38.8 kW
Belt (claimed):54.6 hp
40.7 kW
Chamberlain 55DA Engine
Chamberlain 6.6L 2-cyl diesel
Fuel tank:36 gal
136.3 L
Aux. fuel:1.2 gal
4.5 L
Engine details ...
Mechanical
Chassis:4x2 2WD
Final drives:bull gears
Steering:manual
Brakes:mechanical
Cab:Open operator station.
Transmission:9-speed gear
Transmission details ...
Photos
No photos of the Chamberlain 55DA are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear RPM:540 (1.375)
Dimensions & Tires
Wheelbase:83 inches
210 cm
Weight:9000 lbs
4082 kg
Front tire:8.25x20
Rear tire:18x26
Full dimensions and tires ...
55DA Serial Numbers
6/1954: 101
1/1955: 110
12/1955: 281
7/1956: 431
Final: 441

how to read serial numbers...

Belt Pulley
Diameter:13 inches
33 cm
Width:7 inches
17 cm
RPM:810
Speed:2740 ft/min
835.15 meters/min
Battery
