Cub Cadet 7233 - engine

Cub Cadet 7233 tractor photo
1996 - 1997   7000 Series
Compact Utility tractor
Series next:Cub Cadet 7234
Series back:Cub Cadet 7232
more Cub Cadet 7233 specifications...


Engine Detail:

 Mitsubishi K3G
 liquid-cooled overhead valve (OHV)
 75.4 ci [1.2 L]
Bore/Stroke:3.228x3.071 inches [82 x 78 mm]
Power:23 hp [17.2 kW]
Fuel system:direct injection
Air cleaner:dry
Rated RPM:2500
Idle RPM:970-2750
Firing order:1-3-2
Starter volts:12
Oil capacity:3.7 qts [3.5 L]
Oil change:100 h
Coolant capacity:5.6 qts [5.3 L]
Coolant change:1000 h
Intake valve clearance:0.010 inches [0.254 mm] *Cold
Exhaust valve clearance:0.010 inches [0.254 mm] *Cold
