Tractors > Massey Ferguson > 5465
      -Brand search:


    Massey Ferguson 5465

    Massey Ferguson 5465 tractor photo
    2004 - 2013   5400 Series
    Model years
    Utility tractor
    Next model:Massey Ferguson 5465
    Larger:Massey Ferguson 5470
    Smaller:Massey Ferguson 5460






    Production:

    Manufacturer:Massey Ferguson
    Factory:Beauvais, France


    Massey Ferguson 5465 Engine:

       Perkins 6.0L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:40 gal [151.4 L]
     53.2 gal [201.4 L] (with optional tank)


    3-Point Hitch:

    Rear Type:II
    Rear lift (at 24"/610mm):9,240 lbs [4191 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:540/1000
     540E/1000 (optional)


    Dimensions & Tires:

    Wheelbase:111 inches [281 cm] (2WD)
     109.4 inches [277 cm] (4WD)
    Weight:9810 to 10525 pounds
    full dimensions and tires ...


    5465 Serial Numbers:


    - Serial numbers unknown -



    Massey Ferguson 5465 Power:

    Engine:109 hp [81.3 kW]
    PTO (claimed):95 hp [70.8 kW]
    Drawbar (tested):82.6 hp [61.6 kW]
    PTO (tested):109.4 hp [81.6 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD optional
    Steering:hydrostatic power
    Brakes:independent hydraulic wet disc
    Cab:cab standard


    Hydraulics:

    Type:open center
     closed optional
    Pressure:2684 psi [185.1 bar]
    Valves:2 to 4
    Total flow:15 gpm [56.8 lpm] (open)
     34.8 gpm [131.7 lpm] (combined flow)
     29 gpm [109.8 lpm] (closed)


    Electrical:

    Ground:negative
    Charging amps:80
     120 (optional)


    Battery:

    Cold-cranking amps:505
    Volts:12
