    Massey-Harris Pacemaker

    Massey-Harris Pacemaker tractor photo
    1936 - 1939
    Standard-tread tractor





    The Massey-Harris Pacemaker replaced the Wallis 12/20 in Massey's line. The Twin Power feature increased engine rpms to provide additional horsepower for belt work. The Pacemaker was a standard (wide) front tractor, while the Challenger was the row-crop version.


    Production:

    Manufacturer:Massey-Harris
    Factory:Racine, Wisconsin, USA
    Total built:26,557


    Massey-Harris Pacemaker Engine:

       Massey-Harris 4.1L 4-cyl gasoline
    full engine details ...


    Capacity:

    Fuel:18 gal [68.1 L]
    Aux. fuel:1.6 gal [6.1 L]


    Dimensions & Tires:

    Wheelbase:78 inches [198 cm]
    Weight:3700 lbs [1678 kg]
    Front tire:28x5
    Rear tire:44x10
    full dimensions and tires ...


    Pacemaker Serial Numbers:

    Location:On rear-left portion of tractor frame.

    - Serial numbers unknown -



    Massey-Harris Pacemaker Power:

    Drawbar (claimed):16 hp [11.9 kW]
    Belt (claimed):27 hp [20.1 kW]
    Drawbar (tested):30.58 hp [22.8 kW]
    Belt (tested):42.13 hp [31.4 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
    Cab:Open operator station.


    Belt Pulley:

    Diameter:12 inches [30 cm]
    Width:6.25 inches [15 cm]
    RPM:832
