    Massey-Harris 15/22 GP

    Massey-Harris 15/22 GP tractor photo
    1930 - 1936
    Four-wheel Drive (4WD) tractor





    The Massey-Harris 15/22 GP General Purpose tractor was the first Massey-Harris designed tractor.


    Production:

    Manufacturer:Massey-Harris
    Factory:Racine, Wisconsin, USA
    Total built:3,000
    Original price (USD):$1,000


    Massey-Harris GP Engine:

       Hercules 3.7L 4-cyl gasoline
    full engine details ...


    Capacity:

    Fuel:14 gal [53.0 L]
    Aux. fuel:1.6 gal [6.1 L]


    Dimensions & Tires:

    Weight:3,900 lbs [1769 kg]
    Front tire:38x8
    Rear tire:38x8
    full dimensions and tires ...


    GP Serial Numbers:

    Location:Left-rear of tractor frame.
    1930: 300001
    1936: 303001

    how to read serial numbers...



    Massey-Harris GP Power:

    Drawbar (claimed):15 hp [11.2 kW]
    Belt (claimed):22 hp [16.4 kW]
    Plows:2 (14-inch)
    Drawbar (tested):19.91 hp [14.8 kW]
    Belt (tested):24.84 hp [18.5 kW]
    power test details ...


    Mechanical:

    Chassis:4x4 4WD
    Cab:Open operator station.


    Belt Pulley:

    Diameter:12.125 inches [30 cm]
    Width:6.5 inches [16 cm]
    RPMs:802
    Speed:2.546 ft/min [0.78 meters/min]
