Massey Ferguson 1531
| | 2005 - 2010 |
| 1500 Series | | Compact Utility tractor | | Iseki built |
|
| Production |
| Distributor: | Massey Ferguson
|
| Manufacturer: | Iseki
|
| Type: | Compact Utility tractor
|
| Factory: | Matsuyama, Japan
|
| Original price: | $15,716 (2009 )
|
| Massey Ferguson 1531 Power |
| Engine (gross): | 33 hp
24.6 kW
|
| Engine (net): | 32 hp
23.9 kW
|
| PTO (claimed): | 24.5 hp
18.3 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post folding ROPS.
|
| Transmission: | hydrostatic
|
 Transmission details ... |
| Photos |
| No photos of the Massey Ferguson 1531 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel: | 7.9 gal
29.9 L
|
| Front axle: | 4.7 qts
4.4 L
|
| Hydraulics |
| Type: | open center
|
| Valves: | 2*Optional
|
| Pump flow: | 7.7 gpm
29.1 lpm
|
| Total flow: | 10.4 gpm
39.4 lpm
|
| Steering flow: | 2.7 gpm
10.2 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position control
|
| Rear lift (at ends): | 2425 lbs
1099 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic
|
| Rear RPM: | 540 (1.375)
|
| Mid PTO: | independent
|
| Clutch: | electro-hydraulic
|
| Mid RPM: | 2000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Battery CCA: | 582
|
| Battery volts: | 12
|
