McCormick Intl MTX155
|
|
| Production | |
| Manufacturer | McCormick Intl (a part of Argo) |
| Row-Crop tractor | |
| Built in Doncaster, England | |
| McCormick Intl MTX155 Engine | |
| Perkins 6.0L 6-cyl diesel | |
| Fuel tank | 91.7 gal 347.1 L |
 Engine details ... | |
| McCormick Intl MTX155 Transmissions | |
| 16-speed four-speed power shift | |
| 32-speed creeper | |
 Transmission details ... |
| McCormick Intl MTX155 Power | |
| Engine | 160 hp 119.3 kW |
| Drawbar (claimed) | 125 hp 93.2 kW |
| PTO (claimed) | 141 hp 105.1 kW |
| Drawbar (tested) | 125.4 hp 93.5 kW |
| PTO (tested) | 144.0 hp 107.4 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the McCormick Intl MTX155 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | pressure flow compensating |
| Pump flow | 32 gpm 121.1 lpm |
| SCV flow | 28 gpm 106.0 lpm |
| Tractor hitch | |
| Rear Type | III |
| Control | electronic lower link draft sensing |
| Rear lift (at 24"/610mm) | 15290 lbs 6935 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1877 |
| 1000@2200 | |
| Dimensions & Tires | |
| Wheelbase | 112.2 inches 284 cm |
| Weight | 14440 to 16285 pounds |
| Front tire | 480/70R30 |
| Rear tire | 20.8R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 95 |
| Battery volts | 12 |
| References | |
 | |
| MTX Series published in 2000, by McCormick |
