Steyr 9094



Steyr 9094 tractor photo
1993 - 1995
9000 Series
Row-Crop tractor
Series map:
9086
9094
64.1kw
70.1kw
Production
ManufacturerSteyr
Row-Crop tractor
Steyr 9094 Engine
MWM 4.2L 4-cyl diesel
Fuel tank26.4 gal
99.9 L
 39.6 gal*Total capacity with optional 50L fuel tank.
149.9 L
Engine details ...
Steyr 9094 Transmissions
16-speed synchronized
16-speed
Transmission details ...
Steyr 9094 Power
Engine94 hp
70.1 kW
PTO (claimed)87 hp
64.9 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with heat. Air-conditioning optional.
Photos
No photos of the Steyr 9094 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2538 psi
175.0 bar
Pump flow13.2 gpm
50.0 lpm
 25.4 gpmOptOptional
96.1 lpm
Total flow28.3 gpm
107.1 lpm
 40.4 gpmOptOptional
152.9 lpm
Tractor hitch
Rear lift9922.5 lbs
4500 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Engine RPM390@1933
 540@2045
 540E@1506
 1000@2130
Front PTOoptional
Front PTO Type1000
Engine RPM1000@1933
Dimensions & Tires
Wheelbase97.5 inches
247 cm
Weight8,644 lbs
3920 kg
Front tire14.9R24
Rear tire16.9R38
Full dimensions and tires ...
References
9094 references literature
Steyr 9000 published in 1993
