Montana 5740


Montana 5740 tractor photo
2005 - 2009
Compact Utility tractor
LG built
Series:57205740
Production
Distributor:Montana
Manufacturer:LG
Type:Compact Utility tractor
Factory:South Korea
Variants
5720:ROPS 2WD
5720C:Cab 2WD
5740:ROPS 4WD
5740C:Cab 4WD
Montana 5740 Power
Engine:57 hp
42.5 kW
Montana 5740 Engine
Mitsubishi 3.3L 4-cyl diesel
Cab Fuel tank:13.5 gal
51.1 L
ROPS Fuel tank:15.9 gal
60.2 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power
Brakes:wet disc
Cab:ROPs or Big Sky cab
Transmission:16-speed sync shuttle
Transmission details ...
Hydraulics
Valves:2
Pump flow:8.72 gpm
33.0 lpm
Tractor hitch
Rear Type:I
Rear lift (at ends):3527 lbs
1599 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Dimensions & Tires
Wheelbase:81.7 inches
207 cm
Weight:4650 to 5555.6 pounds
Front tire:11.2-20
Rear tire:14.9-28
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:50
Battery volts:12
Page information
Last update:December 21, 2018
Copyright:Copyright 2021 TractorData LLC
Contact:Peter@TractorData.com
