John Deere 3203
|
|
| Production | |
| Manufacturer | John Deere |
| Compact Utility tractor | |
| Built in Augusta, Georgia, USA | |
| John Deere 3203 Engine | |
| Yanmar 1.5L 3-cyl diesel | |
 Engine details ... |
| John Deere 3203 Transmission | |
| hydrostatic | |
 Transmission details ... |
| John Deere 3203 Power | |
| Engine (gross) | 32 hp 23.9 kW |
| PTO (claimed) | 24 hp 17.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical |
| Power steering | |
| Wet disc brakes | |
| Two-post ROPS. | |
| Photos | |
 | |
 John Deere 3203 photos... | |
| Capacity | |
| Fuel | 11.5 gal 43.5 L |
| Hydraulic system | 6.8 gal 25.7 L |
| Hydraulics | |
| Type | open center |
| Capacity | 6.8 gal 25.7 L |
| Pressure | 2150 psi 148.2 bar |
| Valves | 2 |
| Pump flow | 7.6 gpm 28.8 lpm |
| Total flow | 13.3 gpm 50.3 lpm |
| Steering flow | 5.7 gpm 21.6 lpm |
| Steering press. | 1500 psi 103.4 bar |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 2149 lbs 974 kg |
| Rear lift (at 24"/610mm) | 1868 lbs 847 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | wet disc |
| Rear PTO Type | 540 |
| Engine RPM | 540@2400 |
| Dimensions & Tires | |
| Wheelbase | 68 inches 172 cm |
| Weight | 2700 lbs 1224 kg |
| Front tire | 25x8.50-14 |
| Rear tire | 15-19.5 |
 Full dimensions and tires ... | |
| John Deere 3203 attachments | |
| front-end loader | |
 Attachment details ... |
| 3203 Serial Numbers | |
| 2006 | LV3203H190001 |
| 2007 | LV3203H394001 |
| 2008 | LV3203H496001 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging amps | 75 |
| Battery CCA | 500 |
| Battery volts | 12 |
| Battery Group | 22NF |
| References | |
 | |
| 3000 Series published in 2008, by John Deere | |
| Operator's Manual 3203 Compact Utility Tractor (OMLVU17604) published in 2007 |
