International Harvester TD-15
|
|
| Production | |
| Manufacturer | International Harvester |
| Agricultural Crawler tractor | |
| Built in Melrose Park, Illinois, USA | |
| Total built | 3,500 |
| International Harvester TD-15 Engine | |
| International Harvester 9.1L 6-cyl diesel | |
| Fuel tank | 61 gal 230.9 L |
| Aux. fuel | 1.33 gal 5.0 L |
 Engine details ... | |
| International Harvester TD-15 Transmission | |
| 6-speed shuttle | |
 Transmission details ... |
| International Harvester TD-15 Power | |
| Engine (net) | 105 hp 78.3 kW |
| Drawbar (claimed) | 85 hp 63.4 kW |
| Drawbar (tested) | 76.97 hp 57.4 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | crawler |
| Open operator station. | |
| Dimensions & Tracks | |
| Weight | 22540 lbs 10224 kg |
| 16-inch tracks | |
 Full dimensions and tracks ... | |
| International Harvester TD-15 attachments | |
| front-end loader | |
 Attachment details ... |
| TD-15 Serial Numbers | |
| Location: | Serial number plate on the lower-right of the dashboard. |
| 1958 | 501 (150) |
| 1959 | 577 (150) |
| 1960 | 2456 (150) |
| 1961 | 3501 (150) |
| 1961 | 4001 (151) |
| 1962 | 4680 (151) |
FAQ: How to read a serial number table. | |
| Electrical | |
| Charging system | generator |
| Batteries | 2 |
| Battery volts | 6 |
| References | |
 | |
| Crawler Tractors with Drott 4 in 1 Skid-Shovels published in 1961, by International Harvester |
