Wagner TR-14

Wagner TR-14 tractor photo
1955 - 1960   TR Series
Four-wheel Drive (4WD) tractor
Series back:Wagner TR-9






Production:

Manufacturer:Wagner
Factory:Portland, Oregon


Variants:

TR-14:ag tractor
TRS-14:scraper/dozer tractor


Wagner TR-14 Engine:

   Cummins 12.2L 6-cyl diesel
full engine details ...


Capacity:

Fuel:95 gal [359.6 L]
Hydraulic system:30 gal [113.6 L]


Dimensions & Tires:

Wheelbase:130 inches [330 cm]
Weight:21050 lbs [9548 kg]
Front tire:18.00x26
Rear tire:18.00x26
full dimensions and tires ...


TR-14 Serial Numbers:


- Serial numbers unknown -



Wagner TR-14 Power:

Drawbar (claimed):155 hp [115.6 kW]
Drawbar (tested):148.56 hp [110.8 kW]
power test details ...


Mechanical:

Chassis:4x4 articulated 4WD
Final drives:planetary
Steering:articulated power
Brakes:hydraulic shoe
Cab:Open operator station. Cab optional.


Hydraulics:

Capacity:30 gal [113.6 L]


Battery:

Number:2
Volts:12
