Wagner TR-9
| | 1955 - 1960 |
| TR Series | | Four-wheel Drive (4WD) tractor |
|
| Production |
| Manufacturer: | Wagner
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Portland, Oregon
|
| Variants |
| TR-9: | ag tractor
|
| TRS-9: | scraper/dozer tractor
|
| Wagner TR-9 Power |
| Engine: | 120 hp
89.5 kW
|
| Drawbar (claimed): | 68 hp
50.7 kW
|
| Drawbar (tested): | 87.49 hp
65.2 kW
|
| power test details ... |
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Final drives: | planetary
|
| Steering: | hydraulic power
|
| Brakes: | hydraulic shoe
|
| Cab: | Open operator station. Cab optional.
|
| Transmission: | 10-speed gear
|
 Transmission details ... |
| Capacity |
| Fuel: | 75 gal
283.9 L
|
| Hydraulic system: | 30 gal
113.6 L
|
| Hydraulics |
| Capacity: | 30 gal
113.6 L
|
| Page information |
| Last update: | March 16, 2014
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Wagner TR-9 photos...
Full dimensions and tires ...
