Tractors > McCormick Intl > XTX215

McCormick Intl XTX215

McCormick Intl XTX215 tractor photo
2005 - 2007   XTX Series
Row-Crop tractor
Previous model:McCormick Intl MTX200






Production:

Manufacturer:McCormick Intl
Factory:Doncaster, England


McCormick Intl XTX215 Engine:

   Iveco 6.7L 6-cyl diesel
full engine details ...


Capacity:

Fuel:91.7 gal [347.1 L]


3-Point Hitch:

Rear Type:III
Rear lift:24,144 lbs [10951 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000
 540E/1000 (optional)


Dimensions & Tires:

Wheelbase:113.1 inches [287 cm]
Weight:16010 to 20245 pounds
Front tire:540/65R30
Rear tire:650/65R42
full dimensions and tires ...


XTX215 Serial Numbers:


- Serial numbers unknown -



McCormick Intl XTX215 Power:

Engine:193 hp [143.9 kW]
Drawbar (tested):173.0 hp [129.0 kW]
PTO (tested):205.6 hp [153.3 kW]
power test details ...


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:standard


Hydraulics:

Type:PFC
Total flow:34.1 gpm [129.1 lpm]
 43.1 gpm [163.1 lpm] (optional)


Electrical:

Charging amps:120


Battery:
