John Deere 9200



John Deere 9200 tractor photo
1996 - 2001
Model year
9000 Series
Four-wheel Drive (4WD) tractor
Series map:
9100
9200
9300
260.0hp
310.0hp
360.0hp
Production
ManufacturerJohn Deere
Four-wheel Drive (4WD) tractor
Built in Waterloo, Iowa, USA
John Deere 9200 Engine
John Deere 10.5L 6-cyl diesel
Engine details ...
John Deere 9200 Transmissions
12-speed partially synchronized
24-speed partial power shift
12-speed full power shift
Transmission details ...
John Deere 9200 Power
Engine310 hp
231.2 kW
PTO (claimed)260 hp
193.9 kW
Drawbar (tested)246.46 hp
183.8 kW
PTO (tested)296.92 hp
221.4 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Steeringhydrostatic power
Hydraulic wet disc brakes
Cab standard.
Photos
2000 John Deere 9200 with PTO and three-point hitch.
John Deere 9200 photos...
Capacity
Fuel270 gal
1022.0 L
Hydraulic system26 gal
98.4 L
Hydraulics
Typeclosed center PFC
Capacity26 gal
98.4 L
Pressure2900 psi
200.0 bar
Valves3 to 5
Pump flow35 gpm
132.5 lpm
Total flow44 gpm
166.5 lpm
Tractor hitch
Rear TypeIII
Rear lift13,871 lbs
6291 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM1000 (optional)
Dimensions & Tires
Wheelbase137.8 inches
350 cm
Weight31,015 lbs
14068 kg
Front tire20.8R42
Rear tire20.8R42
Full dimensions and tires ...
9200 Serial Numbers
19971001
199810001
199920001
200030001
200140001

FAQ: How to read a serial number table.
9200 Serial Location
John Deere 9200 serial number location
Serial number plate on the top-left of the tractor's hinge
Electrical
Groundnegative
Charging systemalternator
Charging amps140
Batteries3
Battery CCA925
Battery volts12
References
9200 references literature
New 9000 Series Tractors published in 1996, by John Deere
Typical Questions & Answers - 9000 Series 4WD Tractor Engines published in 1996, by John Deere
The New World Power - 9000 Series Tractors published in 1996, by John Deere
9000 Series Tractors Product Information Handbook published in 1998, by John Deere
9000/9000T Series Tractors Product Information Handbook published in 1999, by John Deere
