J.I. Case 10-18
| | 1918 - 1920 |
| Crossmotor Series | | Standard-tread tractor |
|
Series map:
10-18
20.1hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | J.I. Case
|
| Standard-tread tractor |
| Built in Racine, Wisconsin, USA |
| Total built | 9,051
|
| J.I. Case 10-18 Power |
| Drawbar (claimed) | 10 hp
7.5 kW
|
| Belt (claimed) | 18 hp
13.4 kW
|
| Plows | 2 (14-inch)
|
| Drawbar (tested) | 11.24 hp
8.4 kW
|
| PTO (tested) | 18.1 hp
13.5 kW
|
| Belt (tested) | 18.145 hp
13.5 kW
|
 Performance test details ... |
| Mechanical |
| Two-wheel drive |
| Steering | manual
|
| Open operator station. |
| Photos |
| No photos of the J.I. Case 10-18 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Belt Pulley |
| Diameter | 14.25 inches
36 cm
|
| Width | 5.25 inches
13 cm
|
| RPM | 1050
|
| Speed | 3,916 ft/min
1193.60 meters/min
|
| References |
 |
| Instructions on Operation and Care of the CASE 12-20 Tractor published in 1922 |
| Power Farming Machinery published in 1919, by J.I. Case |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on January 16, 2012 |
