New Holland 9184


New Holland 9184 tractor photo
2000 - 2001
84 Series
Four-wheel Drive (4WD) tractor
Versatile built
Series map:
9184
9384
240.0hp
270.0hp
Production
DistributorNew Holland
ManufacturerVersatile
Four-wheel Drive (4WD) tractor
Built in Winnipeg, Manitoba, Canada
New Holland 9184 Power
Engine (gross)240 hp
179.0 kW
Drawbar (tested)200.6 hp
149.6 kW
PTO (tested)233.6 hp
174.2 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesplanetary
Articulated power steering
Hydraulic disc brakes
Cab standard with air-conditioning.
Photos
No photos of the New Holland 9184 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel230 gal
870.6 L
Hydraulic system20 gal (reservoir)
75.7 L
 33 gal (total system)
124.9 L
Hydraulics
Typeclosed center
Capacity20 gal (reservoir)
75.7 L
 33 gal (total system)
124.9 L
Pressure2250 psi
155.1 bar
Valves4
Pump flow45 gpm
170.3 lpm
Steering flow27 gpm
102.2 lpm
Steering press.2500 psi
172.4 bar
Tractor hitch
Rear TypeIVN/III
Rear lift (at 24"/610mm)13000 lbs
5896 kg
DrawbarCat. 4
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type1000 (1.75)
Engine RPM1000@2100
Dimensions & Tires
Wheelbase133 inches
337 cm
Weight17122 to 24970 pounds
Front tire18.4-38
Rear tire18.4-38
Full dimensions and tires ...
9184 Serial Numbers
Location:Serial number plate mounted on the tractor cab's left, rear, corner.
2001D108097
2002D108515

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps130
Batteries3
Battery CCA625
Battery volts12
References
9184 references literature
84 Series 4WD Tractors published in 1999, by New Holland
Operator's Manual 9184 - 9384 - 9484 - 9684 - 984 (86584305) published in 1999
