    New Holland TC25

    New Holland TC25 tractor photo
    1999 - 2003   Boomer TC Series
    Compact Utility tractor
    Previous model:New Holland 1530
    Larger:New Holland TC29
    Smaller:New Holland TC24D





    The New Holland TC25D was available only in four-wheel drive and with the hydrostatic transmission.


    Production:

    Manufacturer:New Holland
    Original price (USD):$16,000 (2000)


    Variants:

    TC25:base model
    TC25D:deluxe


    New Holland TC25 Engine:

       Shibura 1.3L 3-cyl diesel
    full engine details ...


    Capacity:

    Fuel:7.3 gal [27.6 L]


    3-Point Hitch:

    Rear Type:1
    Rear lift (at 24"/610mm):1,635 lbs [741 kg]


    Power Take-off (PTO):

    Rear PTO:transmission (gear)
     live (hydro)
    Rear RPM:540
    Mid PTO:optional
    Mid RPM:2000


    Dimensions & Tires:

    Wheelbase:63 inches [160 cm]
    SuperSteer Wheelbase:72 inches [182 cm]
    Weight:2334 to 2588 pounds
    Front tire:5.50-16
    Rear tire:11.2-24
    full dimensions and tires ...


    New Holland TC25 attachments:

     front-end loader
    all TC25 attachments ...


    TC25 Serial Numbers:


    - Serial numbers unknown -



    New Holland TC25 Power:

    Engine (gross):25 hp [18.6 kW]
    PTO (claimed):21.7 hp [16.2 kW] (gear)
     20.3 hp [15.1 kW] (hydro)


    Mechanical:

    Chassis:4x4 MFWD 4WD
    Steering:hydrostatic power
    Cab:Two-post ROPS.


    Hydraulics:

    TC25 Pump flow:6.1 gpm [23.1 lpm]
    TC25D Pump flow:7.1 gpm [26.9 lpm]
    TC25 Total flow:10.1 gpm [38.2 lpm]
    TC25D Total flow:12.7 gpm [48.1 lpm]
    TC25 Steering flow:3.5 gpm [13.2 lpm]
    TC25D Steering flow:5.1 gpm [19.3 lpm]


    Electrical:

    Ground:negative


    Battery:

    Number:1
    Volts:12
