Tractors > Allis Chalmers > HD7W

Allis Chalmers HD7W - tests

Allis Chalmers HD7W tractor photo
1940 - 1950
Agricultural Crawler tractor
more Allis Chalmers HD7W specifications...






Nebraska Tractor Test 360:

HD7W fuel use from test 360
Test Date:October 15 - 21, 1940
Type:Diesel 4-speed crawler
Belt power (max):68.68 hp [51.2 kW]
Belt fuel use (max):4.8 gal/hour [18.2 l/hour]
Drawbar power (max):57.31 hp [42.7 kW]
Drawbar pull (max):12,171 lbs [5520 kg]
Max pull gear:1
Test report:PDF file
