Tractors > Century > C47

Century C47

No photo available
2005 - 2006
Compact Utility tractor
Series back:Century C42






Production:

Distributor:Century
Manufacturer:Kukje
Factory:Yangsu-ri, South Korea


Century C47 Engine:

   Kukje 2.3L 4-cyl diesel
full engine details ...


Capacity:

Fuel:11.1 gal [42.0 L]
Hydraulic system:9.25 gal [35.0 L]
Front axle:7.4 qts [7.0 L]


3-Point Hitch:

Rear Type:I
Rear lift:2580 lbs [1170 kg]


Power Take-off (PTO):

Rear PTO:live (2-stage clutch)
Rear RPM:540/1000


Dimensions & Tires:

Wheelbase:71 inches [180 cm]
Weight:3,910 lbs [1773 kg]
Front tire:8-18
Rear tire:12.4-28
full dimensions and tires ...


C47 Serial Numbers:

Location:Below PTO on rear of tractor.

- Serial numbers unknown -



Century C47 Power:

Engine:47 hp [35.0 kW]
PTO (claimed):40 hp [29.8 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Differential lock:foot pedal
Steering:hydrostatic power
Brakes:differential wet disc
Cab:ROPS.


Hydraulics:

Type:open center
Capacity:9.25 gal [35.0 L]
Valves:1 to 3
Pump flow:8.9 gpm [33.7 lpm]
Total flow:13.2 gpm [50.0 lpm]


Electrical:

Ground:negative
Charging amps:45


Battery:

Number:1
Volts:12
