| | Production: |
| Distributor: | Century
|
| Manufacturer: | Kukje
|
| Factory: | Yangsu-ri, South Korea
|
| | |
| Kukje 2.1L 4-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 11.1 gal [42.0 L]
|
| Hydraulic system: | 9.25 gal [35.0 L]
|
| Front axle: | 7.4 qts [7.0 L]
|
| | |
| Rear Type: | I
|
| Rear lift (at ends): | 2,580 lbs [1170 kg]
|
| | |
| Rear PTO: | live (2-stage clutch)
|
| Rear RPMs: | 540/1000
|
| | |
| Wheelbase: | 69 inches [175 cm]
|
| Weight: | 3,770 lbs [1710 kg]
|
| Front tire: | 8-18
|
| Rear tire: | 12.4-28
|
| full dimensions and tires ... | | | C42 Serial Numbers: |
| Location: | Rear of tractor, below PTO.
|
- Serial numbers unknown -
|
|
|
|
| | Century C42 Power: |
| Engine: | 42 hp [31.3 kW]
|
| PTO (claimed): | 36 hp [26.8 kW]
|
| | Mechanical: |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | foot pedal
|
| Steering: | hydrostatic power
|
| Brakes: | differential wet disc
|
| Cab: | ROPS.
|
| | Hydraulics: |
| Type: | open center
|
| Capacity: | 9.25 gal [35.0 L]
|
| Valves: | 1 to 3
|
| Pump flow: | 8.9 gpm [33.7 lpm]
|
| Total flow: | 13.2 gpm [50.0 lpm]
|
| | Electrical: |
| Ground: | negative
|
| Charging amps: | 45
|
| | Battery: |
| Number: | 1
|
| Volts: | 12
|
