Century C29
| | 2005 - 2006 |
| Compact Utility tractor | | Kukje built |
|
Series map:
C29
C35
29.0hp
35.0hp
| Production |
| Distributor | Century
|
| Manufacturer | Kukje
|
| Compact Utility tractor |
| Built in Yangsu-ri, South Korea |
| Century C29 Power |
| Engine | 29 hp
21.6 kW
|
| PTO (claimed) | 25 hp
18.6 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | foot pedal
|
| Steering | hydrostatic power
|
| Differential wet disc brakes |
| ROPS. |
| Photos |
| No photos of the Century C29 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 10.6 gal
40.1 L
|
| Hydraulic system | 9.25 gal
35.0 L
|
| Front axle | 7.4 qts
7.0 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 9.25 gal
35.0 L
|
| Valves | 1 to 3
|
| Pump flow | 8.9 gpm
33.7 lpm
|
| Total flow | 13.2 gpm
50.0 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 2,580 lbs
1170 kg
|
| Power Take-off (PTO) |
| Rear PTO | live (2-stage clutch)
|
| Rear PTO Type | 540/1000
|
| C29 Serial Numbers |
| Location: | Rear of tractor below PTO.
|
| Electrical |
| Ground | negative
|
| Charging amps | 45
|
| Battery volts | 12
|
| References |
 |
| Operator's Manual C29. C35. C38L, C42L and C47L (948898) published in 2004 |
