Tractors > Century > C29

Century C29

No photo available
2005 - 2006
Compact Utility tractor
Series next:Century C35






Production:

Distributor:Century
Manufacturer:Kukje
Factory:Yangsu-ri, South Korea


Century C29 Engine:

   Kukje 1.5L 3-cyl diesel
full engine details ...


Capacity:

Fuel:10.6 gal [40.1 L]
Hydraulic system:9.25 gal [35.0 L]
Front axle:7.4 qts [7.0 L]


3-Point Hitch:

Rear Type:I
Rear lift (at ends):2,580 lbs [1170 kg]


Power Take-off (PTO):

Rear PTO:live (2-stage clutch)
Rear RPM:540/1000


Dimensions & Tires:

Wheelbase:65 inches [165 cm]
Weight:3,640 lbs [1651 kg]
Front tire:7-16
Rear tire:12.4-24
full dimensions and tires ...


C29 Serial Numbers:

Location:Rear of tractor below PTO.

- Serial numbers unknown -



Century C29 Power:

Engine:29 hp [21.6 kW]
PTO (claimed):25 hp [18.6 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Differential lock:foot pedal
Steering:hydrostatic power
Brakes:differential wet disc
Cab:ROPS.


Hydraulics:

Type:open center
Capacity:9.25 gal [35.0 L]
Valves:1 to 3
Pump flow:8.9 gpm [33.7 lpm]
Total flow:13.2 gpm [50.0 lpm]


Electrical:

Ground:negative
Charging amps:45


Battery:

Number:1
Volts:12
