Lamborghini Champion 150


Lamborghini Champion 150 tractor photo
1998 - 2004
Champion Series
Row-Crop tractor
Series:Champion 135Champion 150
Champion 200
Production
Manufacturer:Lamborghini
Type:Row-Crop tractor
Lamborghini Champion 150 Power
Engine:150 hp
111.9 kW
Lamborghini Champion 150 Engine
SDF 6.0L 6-cyl diesel
Fuel tank:100.4 gal
380.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:electro-hydraulic front and rear
Steering:power
Brakes:hydraulic wet disc
Trailer brakes:hydraulic
Cab:Cab standard with air-conditioning.
Transmissions:18-speed 9-speed power shift
 27-speed creeper
Transmission details ...
Photos
No photos of the Lamborghini Champion 150 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
 load-sensing*Optional
Valves:8*Optional
Pump flow:19.3 gpm
73.1 lpm (open)
 27.2 gpm
103.0 lpm (load-sensing)
Tractor hitch
Rear lift:15432 lbs
6999 kg
 18960 lbs
8600 kg *With optional lift cylinders.
Front lift:8818 lbs
3999 kg *Optional
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic wet disc
Rear RPM:540/1000
 540E/1000
Front PTO:independent*Optional
Clutch:electro-hydraulic
Front RPM:1000
Dimensions & Tires
Wheelbase:108.3 inches
275 cm
Weight:13448 lbs
6100 kg
Front tire:480/70R30
Rear tire:580/70R38
Full dimensions and tires ...
Electrical
Charging system:alternator
