Volvo T810
| | 1969 - 1978 |
| Row-Crop tractor |
|
Series map:
T800
T810
T814
79.0kw
99.2kw
84.3kw
| Production |
| Manufacturer | Volvo
|
| Row-Crop tractor |
| Built in Eskilstuna, Sweden |
| Total built | 3550
|
| Original price | $40,000 (1978)
|
| Volvo T810 Power |
| Engine | 133 hp
99.2 kW
|
| Mechanical |
| Two-wheel drive |
| Differential lock | standard
|
| Steering | hydrostatic power
|
| Disc brakes |
| Cab optional with heat |
| Photos |
| No photos of the Volvo T810 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | Trac-Trol
|
| Pressure | 2275 psi
156.9 bar
|
| Valves | 2
|
| Pump flow | 7.9 gpm
29.9 lpm
|
| | 11.9 gpm (optional)
45.0 lpm
|
| Tractor hitch |
| Rear lift | 5,200 lbs
2358 kg
|
| | 6,170 lbs (optional)
2798 kg
|
| Power Take-off (PTO) |
| Rear PTO Type | 1000
|
| | 540/1000
|
| References |
 |
| Volvo BM T 500 published in 1971 |
