Tractors > Fordson > E27N Major

Fordson E27N Major - engine

Fordson E27N Major tractor photo
1945 - 1952
Previous model:Fordson Fordson N
Next model:Fordson New Major
more Fordson E27N Major specifications...






Engine Detail:

The E27N Major was available with high-compression heads for running on petrol, or low-compression heads for using TVO. TVO tractors had an auxiliary petrol fuel tank for starting.
 Ford
 gasoline
 4-cylinder
 liquid-cooled
 267 ci [4.4 L]
Bore/Stroke:4.125x5.00 inches [105 x 127 mm]
Power:27 hp [20.1 kW]
Rated RPM:1200
Firing order:1-2-4-3
Starter volts:12
Oil capacity:12.6 qts [11.9 L]
Coolant capacity:48.1 qts [45.5 L]


Engine Detail:

The Perkins diesel conversion first occured in 1950, after numerous problems with the kerosene engine, whose design was nearly 30 years old. Tractors with the diesel are known as E27N P6(TA).
 Perkins
 diesel
 6-cylinder
 liquid-cooled
 288 ci [4.7 L]
Bore/Stroke:3.50x5.00 inches [89 x 127 mm]
Power:45 hp [33.6 kW]
Rated RPM:1500
