McCormick Intl ZTX260
|
|
| Production | |
| Manufacturer | McCormick Intl (a part of Argo) |
| Row-Crop tractor | |
| Built in Doncaster, England | |
| McCormick Intl ZTX260 Engine | |
| Cummins 8.3L 6-cyl diesel | |
| Fuel tank | 150.6 gal 570.0 L |
 Engine details ... | |
| McCormick Intl ZTX260 Transmissions | |
| 18-speed full power shift | |
| 36-speed creeper | |
 Transmission details ... |
| McCormick Intl ZTX260 Power | |
| Engine | 260 hp 193.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the McCormick Intl ZTX260 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load-sensing |
| Pump flow | 29.1 gpm 110.1 lpm |
| 39.6 gpmOptOptional 149.9 lpm | |
| Tractor hitch | |
| Rear Type | III |
| Rear lift | 24255 lbs 11002 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 (1.375) |
| 1000 (1.75) | |
| Engine RPM | 540E@1400 |
| 1000@2090 | |
| Dimensions & Tires | |
| Wheelbase | 120.1 inches 305 cm |
| Weight | 22491 lbs 10201 kg |
| Front tire | 540/65R30 |
| Rear tire | 650/65R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 150 |
| References | |
 | |
| ZTX published in 2005, by McCormick | |
| The ZTX Series published in 2003, by McCormick |
