Tractors > McCormick Intl > MC120 Power6

McCormick Intl MC120 Power6

McCormick Intl MC120 Power6 tractor photo
2003 - 2007   MC Series
Utility tractor
Series next:McCormick Intl MC135
Series back:McCormick Intl MC115






Production:

Manufacturer:McCormick Intl
Factory:Doncaster, England


McCormick Intl MC120 Engine:

   Perkins 6.0L 6-cyl diesel
full engine details ...


Capacity:

Fuel:70 gal [264.9 L]
Hydraulic system:19.8 gal [74.9 L]


3-Point Hitch:

Rear Type:2N
Control:electronic lower link draft sensing
Rear lift (at ends):11,234 lbs [5095 kg]
 13,137 lbs [5958 kg] (optional)
Rear lift (at 24"/610mm):8,201 lbs [3719 kg]
 10,180 lbs [4617 kg] (optional)


Power Take-off (PTO):

Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540/1000
Engine RPM:540@2136
1000@2200


Dimensions & Tires:

Wheelbase:104.3 inches [264 cm]
Weight:11124 to 12742 pounds
Front tire:11.00x16
Rear tire:18.4R38 (2WD)
full dimensions and tires ...


McCormick Intl MC120 attachments:

 front-end loader
all MC120 attachments ...


MC120 Serial Numbers:


- Serial numbers unknown -



McCormick Intl MC120 Power:

Engine:115 hp [85.8 kW]
PTO (claimed):98 hp [73.1 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD (optional)
Differential lock:electro-hydraulic wet clutch
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post foldable ROPS. Cab optional.


Hydraulics:

Type:pressure flow compensated (PFC)
Capacity:19.8 gal [74.9 L]
Valves:2 to 4
Pump flow:28.8 gpm [109.0 lpm]
SCV flow:25.1 gpm [95.0 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:95


Battery:

Volts:12
