McCormick Intl C90


McCormick Intl C90 tractor photo
2001 - 2003
C Series
Utility tractor
Series:C80C90C100
Production
Manufacturer:McCormick Intl (a part of Argo)
Type:Utility tractor
Factory:Doncaster, England
McCormick Intl C90 Power
Engine:90 hp
67.1 kW
PTO (claimed):74 hp
55.2 kW
Drawbar (tested):69.2 hp
51.6 kW
PTO (tested):79.7 hp
59.4 kW
power test details ...
McCormick Intl C90 Engine
Perkins 4.0L 4-cyl diesel
Fuel tank:31.7 gal
120.0 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post ROPS.
Transmissions:8-speed synchromesh
 8-speed shuttle
 16-speed two-speed power shift
Transmission details ...
Photos
No photos of the McCormick Intl C90 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pressure:2500 psi
172.4 bar
Pump flow:15.5 gpm
58.7 lpm
Tractor hitch
Rear Type:II
Rear lift:3664 lbs
1661 kg
 5097 lbs
2311 kg *Optional
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Engine RPM:540@1994
1000@2000
Dimensions & Tires
2WD Wheelbase:84.3 inches
214 cm
4WD Wheelbase:88 inches
223 cm
Weight:5964 to 6692 pounds
Front tire:11.00-16
2WD Rear tire:18.4-30
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
