    John Deere 8330

    John Deere 8330 tractor photo
    2006 - 2009   8030 Series
    Row-Crop tractor
    Previous model:John Deere 8320
    Next model:John Deere 8295R
    Larger:John Deere 8430
    Smaller:John Deere 8230






    Production:

    Manufacturer:John Deere
    Factory:Waterloo, Iowa, USA


    Variants:

    8330:row-crop tractor
    8330T:crawler tractor


    John Deere 8330 Engine:

       John Deere 9.0L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:180 gal [681.3 L]
    Hydraulic system:9.5 gal [36.0 L]
     14.5 gal [54.9 L] (with aux reservoir)


    3-Point Hitch:

    Rear Type:III/IIIN
     IVN/III (optional)
    Rear lift (at 24"/610mm):12,400 lbs [5624 kg]
     15,200 lbs [6894 kg] (optional)
     18,300 lbs [8300 kg] (optional)


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:1000
     540/1000 (optional)
    Engine RPM:540@1817
    1000@2000


    Dimensions & Tires:

    Wheelbase:118.9 inches [302 cm] (ILS)
     120.1 inches [305 cm] (MFWD)
    Weight:23747 to 25147 pounds
    full dimensions and tires ...


    8330 Serial Numbers:

    Location:Rear of tractor.

    - Serial numbers unknown -



    John Deere 8330 Power:

    Engine (gross):275 hp [205.1 kW]
    Engine (max):300 hp [223.7 kW]
    PTO (claimed):225 hp [167.8 kW]
    Drawbar (tested):237.2 hp [176.9 kW]
    PTO (tested):261.5 hp [195.0 kW]
    power test details ...


    Mechanical:

    Chassis:4x4 MFWD 4WD
     4x4 Independent Link Suspension (ILS) MFWD 4WD optional
    Steering:hydrostatic power
    Brakes:wet disc
    Cab:CommandView cab standard.


    Hydraulics:

    Type:closed center PFC
    Capacity:9.5 gal [36.0 L]
     14.5 gal [54.9 L] (with aux reservoir)
    Pressure:2098 psi [144.7 bar]
    Valves:3 to 5
    Pump flow:31.7 gpm [120.0 lpm]
    Total flow:44 gpm [166.5 lpm]
     60 gpm [227.1 lpm] (optional)


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:200


    Battery:

    Number:2
    Cold-cranking amps:925
    Volts:12
