Fendt Farmer 307


Fendt Farmer 307 tractor photo
1993 - 1998
Farmer 300 Series
Row-Crop tractor
Series map:
Farmer 307
Farmer 308
55.9kw
71.6kw
Production
ManufacturerFendt
Row-Crop tractor
Fendt Farmer 307 Engine
MWM 3.1L 3-cyl diesel
Fuel tank21.1 gal
79.9 L
Engine details ...
Fendt Farmer 307 Power
Engine75 hp
55.9 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Fendt Farmer 307 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow18.8 gpm
71.2 lpm
Tractor hitch
Rear lift8859 lbs
4018 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/750/1000
Front PTOindependent OptOptional
Clutchelectro-hydraulic
Front PTO Type1000
Dimensions & Tires
Wheelbase84.7 inches
215 cm
Weight8489 lbs
3850 kg
Front tire380/70R24
Rear tire480/70R34
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps95
Battery volts12
Battery AH90
References
Farmer 307 references literature
Farmer 307 - 308 - 309 - 310 - 311 - 312 published in 1993, by Fendt
