Fendt Farmer 108LS
| | 1977 - 1980 |
| Farmer 100 Series | | Row-Crop tractor |
|
| Production |
| Manufacturer: | Fendt
|
| Type: | Row-Crop tractor
|
| Fendt Farmer 108LS Power |
| Engine: | 73.8 hp
55.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| Cab: | Cab standard with available heater.
|
| Transmissions: | 13-speed synchronized
|
| | 16-speed creeper
|
 Transmission details ... |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2538 psi
175.0 bar
|
| Pump flow: | 12.4 gpm
46.9 lpm
|
| Tractor hitch |
| Rear lift: | 7695 lbs
3490 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 28
|
| Charging volts: | 14
|
| Battery volts: | 12
|
| Battery AH: | 110
|
