Yanmar YM1401


Yanmar YM1401 tractor photo
1979 - 1981
Compact Utility tractor
Production
Manufacturer:Yanmar
Type:Compact Utility tractor
Variants
YM1401:2WD
YM1401D:4WD
Yanmar YM1401 Power
Engine:13.8 hp
10.3 kW
Yanmar YM1401 Engine
Yanmar 0.9L 3-cyl diesel
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Cab:Open operator station.
Transmission:6-speed gear
Transmission details ...
Photos
No photos of the Yanmar YM1401 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear RPM:540 (1.375)
Engine RPM:520@2400
862@2400
1300@2400
Dimensions & Tires
Wheelbase:49.4 inches
125 cm
Weight:1080 to 1168 pounds
Front tire:4.50-10
2WD Rear tire:8-16
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
Battery AH:45
