Tractors > Challenger > MT845B

Challenger MT845B

Challenger MT845B tractor photo
2005 - 2008   MT800B Series
Agricultural Crawler tractor
Next model:Challenger MT845C
Series next:Challenger MT855B
Series back:Challenger MT835B






Production:

Manufacturer:Challenger (a part of AGCO)


Challenger MT845B Engine:

   Caterpillar 15.2L 6-cyl diesel
full engine details ...


Capacity:

Fuel:305 gal [1154.4 L]
 330 gal [1249.1 L] *Optional


3-Point Hitch:

Rear Type:III/IVN
Rear lift:19500 lbs [8845 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:1000


Dimensions & Tires:

Wheelbase:118 inches [299 cm]
Weight:43075 lbs [19538 kg]
Front tire:tracks
Rear tire:tracks
full dimensions and tires ...


MT845B Serial Numbers:


how to read serial numbers...



Challenger MT845B Power:

Engine:400 hp [298.3 kW]
PTO (claimed):335 hp [249.8 kW]
Drawbar (tested):313.27 hp [233.6 kW]
PTO (tested):402.32 hp [300.0 kW]
power test details ...


Mechanical:

Chassis:crawler
Cab:Cab standard.


Hydraulics:

Type:closed center PFC
Pressure:2900 psi [200.0 bar]
Valves:4
 6*Optional
Total flow:43.5 gpm [164.6 lpm]
 59 gpm [223.3 lpm] *Optional


Electrical:

Ground:negative
Charging amps:185


Battery:

Number:4
Cold-cranking amps:1000
Volts:12


Page information:
