International Harvester 785
|
|
| Production | |
| Manufacturer | International Harvester |
| Utility tractor | |
| Built in Doncaster, England | |
| International Harvester 785 Engine | |
| International Harvester 4.0L 4-cyl diesel | |
| Fuel tank | 29.6 gal 112.0 L |
 Engine details ... | |
| International Harvester 785 Transmissions | |
| 8-speed synchromesh | |
| 16-speed two-speed power shift | |
 Transmission details ... |
| International Harvester 785 Power | |
| Engine (gross) | 80 hp 59.7 kW |
| Engine (net) | 77.4 hp 57.7 kW |
| PTO (claimed) | 68.3 hp 50.9 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard. Economy and Deluxe cabs available. | |
| Hydraulics | |
| Pump flow | 12.4 gpm 46.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 4400 lbs 1995 kg |
| 5250 lbs*With optional assistor ram 2381 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Wheelbase | 88.19 inches 224 cm |
| Front tire | 10.00-16 |
| Rear tire | 16.9-34 |
 Full dimensions and tires ... | |
| 785 Serial Numbers | |
| Location: | Serial number plate on right front of tractor frame, above the front axle. |
| Electrical | |
| Ground | negative |
| References | |
 | |
| Field Force published in 1981, by International Harvester | |
| 85 Series published in 1981, by International Harvester | |
| 85 Series published by International Harvester |
