UTB/Universal 510
|
|
| Production | |
| Manufacturer | UTB/Universal |
| Utility tractor | |
| Built in Brasov, Romania | |
| Original price was $10,500 in 1990 | |
| The Universal Farm Group of Rowlett, Texas sold this model as the Universal 550. | |
| UTB/Universal 510 Engine | |
| UTB 2.7L 3-cyl diesel | |
| Fuel tank | 14.3 gal 54.1 L |
 Engine details ... | |
| UTB/Universal 510 Transmission | |
| 8-speed partially synchronized | |
 Transmission details ... |
| UTB/Universal 510 Power | |
| Drawbar (claimed) | 42 hp 31.3 kW |
| PTO (claimed) | 43 hp 32.1 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | spur gear |
| Differential lock | mechanical rear |
| Power steering | |
| Mechanical band brakes | |
| Two-post ROPS. | |
| Photos | |
| No photos of the UTB/Universal 510 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2133 psi 147.1 bar |
| Valves | 1 |
| Pump flow | 10 gpm 37.9 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift | 3080 lbs 1397 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2160 |
| Dimensions & Tires | |
| 2WD Wheelbase | 75.75 inches 192 cm |
| 4WD Wheelbase | 78 inches 198 cm |
| Weight | 4230 to 5350 pounds |
| Front tire | 6.50x16 |
| 2WD Rear tire | 14.9x28 |
 Full dimensions and tires ... | |
| References | |
 | |
| Universal Tractors published in 1987 |
